Tank Bottom Mounted Stainless Steel Liquid Magnetic Mixer Magnetic Stirrer ( Contact Us For The Best Price )
All Of Our Products Are Customized Based On Your Requirements.
Product Description
This mixing tank is used to mixing material like juice, milk, drink, chemicals, cosmetics and so on.
It is with electric mixer and the motor could be regulated.
It adopts the high quality of SUS304 material and meet with the food grade.
It is easy to operate and washing. Also it could be set with automatic CIP spraying head for more easy washing.
Parameters
Material: SUS304 or SUS316L
Volumn: 50L ~50, 000L
Agitator brand: Chinese brand or European brand
Agitator type: Propeller type, anchor type, scraper type, etc.
Agitator seal: Alloy mechanical seal
Structure: Single layer or with Jacket, jacket for heating(can pass steam, hot water, hot heating oil)
Jacket for cooling, or jacket for both heating and cooling)
Jacket type: Dimple jacket, coil tube.
Temperature Isolation material: PU foam or rock wool
Motor speed: Fixed(36rpm, 60rpm, etc), Adjustable(like 10-100rpm) through frequency inverter.
Reducer type: Cycloidal reducer, stepless speed reducer
Head and bottom: Conical head and bottom or dish head and bottom
Heating way: Steam heating or electricity heating
Design: Easy to operate.
Power: 380V/3/50Hz, 220V/3/60Hz.
Finish: Sanitary finish, without dead angle. Internal surface is mirror polished, outside surface is satin finish.
Tank: This tank is customized, please send us your requirements of the tank.
Configure:
Sanitary manhole, agitator, inlet and outlet, 360 degree rotation spray ball, aseptic air vent, thermometer,
Manometer, level gauge, etc.
Ladder(if needed)
Adjustable legs
We Can Customize The Equipment According To Customer Requirements. | |
Tank Volume | From 50L upto 50000L |
Material | 304 or 316 Stainless steel |
Insulation | Single Layer Or With Insulation |
Top Head type | Dish Top, Open Lid Top, Flat Top |
Bottom type | Dish bottom, Conical bottom, Flat bottom |
Agitator type | impeller, Anchor , Turbine , High shear, magnetic mixer, Anchor mixer with scraper |
Magnetic Mixer, Anchor Mixer With Scraper | |
Inside Finsh | Mirror Polished Ra<0.4um |
Outside Finish | 2B or Satin Finish |
Application | Food, Beverage, Pharmacy, Biological |
Honey, Chocolate, Alcohol ,Chemical Industry Etc | |
Product Pictures
Agitator Inside The Tank, We Have Different Types: Homogenizer, Paddle, Frame, Anchor, Clover Propelled, Stirrer With Scraper ( Other Agitator Can Be Customized )
Customer case--------------
Case 1: Agitator Tanks Installed In Pharmaceutical Factories In The Dominican Republic, Postive Feedback By Our Customers.
Case 2: High Shear Mixing Tanks installed for Paint Factory in US.
CE certificate
--------
Why Choose ACEAce has over 10 years of experience in manufacturing,designing and sales.
Ace is extremely strict with the quality of our products,all the products are tested before shipping.
Ace stocks a wide range of stills and equipments--ready to ship,we can arrange Super fast shipping for our customers.
Ace has a complete production line,this allows us to make custom products with low/no MOQ.
FAQ
---
| Q1 | Are you trade or manufacturer? |
| A | We are a factory with an international sales company specialized in support for global distributors. |
| Q2 | Can you provide instant technical consulting services? |
| A | We are able to discuss technical details and offer suggestions over the phone in English. You can get the answers in minutes, instead of days. |
| Q3 | What's the difference between Ready-To-Ship and Customized products? |
| A | Some of RTS standard products are in stock and ready to ship in 2-3 days. |
| Q4 | What is the payment terms? |
| A | We accept Alibaba Trade Assurance Order, also can T/T and L/C. |
| Q5 | How to choose the shipment way? |
| A | It is according to the order quantity, delivery time, costs and customs policy etc. (Or decide by customers) |
| Q6 | How about the after-sales service? |
| A | Fast after-sales support. Our products have a one-year warranty and free permanent consulting services. |
